Hybrid Inverter, Products
HYS-(3.0-0.6) LV EUG1 Series
Dimensions: 502 × 461× 202mm
Weight: 25kg
Battery voltage range: 40V–60V
Max. battery charge/discharge current: 100A/100A
MPPT voltage range: 125V-500V
Number of MPPTs: 2
Max. PV input Current: 14A/14A
Max. output apparent power (on-grid): 6,000VA
Max. input apparent power (on-grid): 7,360VA
Max. output apparent power (off-grid): 6,000VA
Max. efficiency: 97.6%
Protection degree: IP65
Features
– Intelligent export limitation
– Double MPPT tracker, up to 14A MPPT current
– DC/AC ratio up to 150%
– Ultralight for easy installation and space-saving
– Compatible with multiple batteries, providing users with more choices
– UPS level switching time <10 ms
– Built-in dry contact flexibly set to earth fault alarm, load control or generator control
– Max. 10 parallel inverters
Warranty
– 10 Years
